Standard Recovery Power Modules | Status : Active

MD100C12D1

Check Stock Add To Cart
Datasheet ECAD Model Reliability Data

Product Detail

Part Number Number of Functions VRRM (V) IF(AV)(A)@Tc (°C) IFSM (A) VFM (V) IF(A) IRD (mA) VRD (V) Tc (°C) TVj [max] (°C)
MD100C12D1 Dual 1200 100 2500 1.4 300 5 1200 109 150
Part Number MD100C12D1 Number of Functions Dual VRRM (V)  1200 IF(AV)(A)@Tc (°C)  100 IFSM (A)  2500 VFM (V)  1.4 IF(A)  300 IRD (mA)  5 VRD (V)  1200 Tc (°C)  109 TVj [max] (°C)  150

Packing Information

Part Number Package Type Packing Specification Component Weight (g) Marking Code
MD100C12D1 D1 D1 97.0000 MD100C12D1

Environmental Information link icon

Reliability Report Soldering Profile Environmental Compliance
Configuration image Download Configuration image Download Environmental Compliance Download
MTBF FIT
7494.35 15.2
