Standard Recovery Rectifiers | Status :
Obsoleted
RA501
Last Time Ship Date:08-01-2019
EOL Notice
- Package Type:RA
- Packing Info:Bulk: 1K/Box, 10K/Ctn
- Category:Standard Recovery Rectifiers
Product Detail
| Part Number | Number of Functions | IF(AV)(A) | VRWM (V) | VF (V) [max]@IF(A) |
IR (uA) [max] @ VR |
TRR (μs) | IFSM (A) | IF(A) | VR (V) | Tj [max] (°C) |
|---|---|---|---|---|---|---|---|---|---|---|
| RA501 | Single | 50 | 50 | 1.1 | 5 | 3 | 500 | 50 | 50 |
| Part Number RA501 | Number of Functions Single | IF(AV)(A) 50 | VRWM (V) 50 |
VF (V) [max]@IF(A) 1.1 |
IR (uA) [max] @ VR 5 |
TRR (μs) 3 | IFSM (A) 500 | IF(A) 50 | VR (V) 50 |
Tj [max] (°C) |
Packing Information
| Part Number | Package Type | Packing Specification | Component Weight (g) |
|---|---|---|---|
| RA501 | RA |
RA
|
1.8000 |
Environmental Information
Download
| MTBF | FIT |
|---|---|
| 27479.27 | 4.2 |
ECN/PCN
| ECN/PCN No# | Title | Issued Date | |
|---|---|---|---|
| 070117-2 | MCC switched to unplate process for SRA and RA packages |
|
07/01/2017 |
| 070103 | Pb(Lead) Free Plating Conversion |
|
07/01/2003 |
