Bridge Rectifiers | Status : Obsoleted

MB5010

Last Time Ship Date:06/01/2014 EOL Notice
  • Package Type:MB-35
  • Packing Info:Bulk: 50pcs/Box, 400pcs/Ctn
  • Category:Bridge Rectifiers
Check Stock Add To Cart
Datasheet ECAD Model Reliability Data

Product Detail

Part Number Number of Functions IF(AV)(A) VRWM (V) VF
(V) [max]@IF(A)		 IR (uA)  [max] @
VR		 IFSM (A) IF(A) VR (V) Tj [max] (°C)
MB5010 1-Phase Bridge 50 1000 1.2 10 400 25 1000 125
Part Number MB5010 Number of Functions 1-Phase Bridge IF(AV)(A)  50 VRWM (V)  1000 VF
(V) [max]@IF(A)  1.2 		IR (uA)  [max] @
VR  10 		IFSM (A)  400 IF(A)  25 VR (V)  1000 Tj [max] (°C)  125

Packing Information

Part Number Package Type Packing Specification Component Weight (g) Marking Code
MB5010 MB-35 MB-35 24.0000 MB5010

Environmental Information link icon

Reliability Report Material Composition Data Sheet Soldering Profile Environmental Compliance
Configuration image Download Configuration image Download Configuration image Download Environmental Compliance Download
MTBF FIT
22483.04 5.1

ECN/PCN

ECN/PCN No# Title PDF Issued Date
021110 Bridge Rectifiers Min/Mult Quantity Update PDF 03/01/2010
070103 Pb(Lead) Free Plating Conversion PDF 07/01/2003
